Professional Digital Sound Processor 24 Bits Karaoke Audio Processor System

Guangzhou Concord Sound Industrial Co., Ltd.
Contact Now

Professional Digital Sound Processor 24 Bits Karaoke Audio Processor System

Place of Origin : Guangdong, China

Brand Name : VA

Model Number : DP8

Packaging Details : soft bubble inside,thick carton outside

Supply Ability : 10000 Piece/Pieces per Month

Price : $100.00 - $1,000.00/pieces

Warranty : 1 year

Customized : Yes

Product name : 4-in 8-out professional sound system karaoke audio processor

Item No : DP8

Frequency Response : 20Hz-20kHz, ±0.5dB

Channel : 4 in-4 out

Channel gain : -18 -12dB

Input impedance : >10kΩ

Output Impedance : 50Ω

Power supply : 90-240VAC(50/60Hz)

Interface : 3 pin XLR

RS-485 : 3 Pin m-XLR fm-XLR

Port : Guangzhou, Shenzhen

Contact Now

Product Description

VA professional 4-in 4-out professional sound system karaoke audio processor

Feather:
96kHz sampling frequency 24 bits processing accuracy
Each input channel has 30 parameter equalization
Each output channel has 7 parameter equalization
Unique full pass filter can correct phase curve
A variety of frequency division types and frequency slopes
Each input channel delay 480ms
Each output channel delay 270ms
Output channel with limiter
Built-in noise signal
Up to 32 preset program storage capacity
Provides multiple password protection programs
Connect the computer via USB or RS485
Remote control 32 equipment at the same time
Professional Digital Sound Processor 24 Bits Karaoke Audio Processor System
Specification
DP8
DP12
DP36
Channel
4-in 4-out
2-in 4-out
3-in 6-out
Input impedace
>10KΩ
Output impedace
50Ω
Max SPL
+20dBu
Frequency response
+/-0.5dB (20 to 20kHz)
SNR
112dB typical (dBA)
CMRR
>40dB (20 to 10kHz)
Crosstalk
< -100dB
Distortion
0.005% (1kHz @ 0dBu)
DSP
32 bits (can be 40 bits) Floating Point Unit
Sampling rate
96kHz
ADC/DAC
24 bits high-resolution chip
Transmission delay
1.3ms
Display
2 lines 20 characters backlit LCD
Electric Level
7 LED display
Push-button
6~9 mute switch, 6~9 channals select button, 3 menu key, 3 data adjustment key
Input/output interface
3pin XLR
RS-485
3pin m-XLR fm-XLR
USB connector
Type B
Power
Socket with IEC standard
Power supply
90-240 VAC (50/60Hz)
Cabinet size(l*w*h)
483×44×229mm
Package size(l*w*h)
530*300*90mm
430*305*90mm
N.W(kg)
3.5
3.5
G.W(kg)
3.7
Master gain
-18 to 12bB, 0.1dB stepping
Delay
Each input MAX 480ms
Delay
Each output MAX 270ms
EQ
Each input, 30 PEQ (DP24) 18 PEQ (DP36)
EQ
Each output, 7 EQ
EQ
Oaraneter, HP, LP, shelv, full pass, bass pass, trapper
EQ
-15 to +15dB, 0.5dB stepping
EQ
0.009 to 4.8 octaves (Q=0.3 to 20)
Filter tpyes
Butterworth, Bessel, Linkwitz Riley
Threshold value
-10 to +20dBu
Compression ratio
1:1 to 32:1
Soft and hard inflexion
0% to 100%
Starting time
5 to 200ms
Release time
0.1s to 3s
